USB Signal Tower


LR6-USB USB SIGNAL TOWER

Directly Triggered and Powered via USB interface. Compatible with Windows(R) and Linux.

 Product Features

    • PC or HMI controlled.
    • Custom programming made easy with our free software library (.DLL).
    • Open architecture makes it possible to control the device with other operating systems such as Linux.
    • Supports HID class. No exclusive drivers necessary.
    • Supports solid color, clear-globe, and 7-in-1 multi-color LED units.
    • IP65 protection rating - High water and dust protection.

LR6-USB

Model Specifications

OPERATING VOLTAGES - 5V DC (USB Bus Powered, Rated voltage is compliant with USB 2.0 Standard)
PROTOCOLS - USB 2.0
- Software Library (DLL) compatible with Windows® 7, Windows® 8,
  Windows® 8.1 (excluding Windows® 8RT and 8.1RT) and Windows® 10
- Compatible with open-source software operating systems such as Linux
FUNCTIONS - LED units and Buzzer is controlled by a PC via USB interface.
CONFORMITY STANDARDS - UL
- FCC
- EMC Directive
- RoHS
- KC
PROTECTION RATING - IP65 (IEC 60529), except when pole or wall mounted.
- NEMA Type 4X, 13

Accessories

 Pole Bracket

SZP-004W/U/K
Pole Bracket

Mounting Brackets

SZ-010
Mounting Brackets

Mount Bracket
SZ-016A
Mount Bracket

Wall Mount Bracket for LR6, LR7 Series


SZK-003W/U/K
Wall Mount Bracket for LR6, LR7 Series

LED Light Units for LR6 Series
LR6-E
LED Light Units for LR6 Series
Multi-Color LED Unit for LR6 60mm Signal Towers
LR6-E-MZ
Multi-Color LED Unit for LR6 60mm Signal Towers
